Fabric Shrinking Machine (with spraying humidifying device)

product description

Fabric Shrinking Machine (with spraying humidifying device)

Model: YL-4800-A

                                   Technical Specification
Voltage&FrequencyAC 380V 50HZ
Steam consumption100kg/h
Steam pressure0.4-0.7 Mpa
Maximum roll fabric diameter40cm
Maximum working width2100mm
Working speedAdjustable,0-20m/min
Drying temperatureAdjustable,≤200 ℃
Drain vapor motor power0.8kw
Feeding fabric motor power0.12kw
Sway folding motor power0.37kw
Belt working motor power0.37kw
Spreading fabric motor power0.09kw
Vibration motor power0.09kw
Suction motor power0.8kw
Drying heating power12kw
Total  Power15kw
Boundary dimension5750*2610*1650mm


  • Spraying humidifying ,especially suitable for fabric with strong water-absorbing, better shrinkage effect

  • Steam humidification and heating

  • Two drying areas. Drying is mainly by steam heating, electric heating is auxiliary. Not only for save energy but also meet the temperature requirements of different fabric.

  • Adopt strong cooling device, quickly cooling fabric, stabilize fabric size

  • Vibration function allow the fiber to be fluffy naturally.

  • Spreading fabric 、Measurement、folding fabric


  • Fully sealed unique design steam cover: no leakage of steam, reduce the  steam consumption

  •  (save about 40% steam consumption than other type product), ensure no water dripping

  • The steam cover is made of three layers of stainless steel,good heat preservation and thermal insulation effect

  •  Electronic eye monitoring releasing fabric , make sure fabric is in the tension-free state

  • Stepless Frequency Conversion Timing

  • Equipped with original imported electrical appliances, stable performance,machine is durable

  • Electronic eye automatically adjusts the mesh belt no need to worry about  mesh belt running off, automatically stop working in case of failure

  • Use high temperature resistant Teflon mesh belt

Suitable for

Special for cotton and linen weaving fabric, cotton and linen chemical fabric, woolen fabric and other fabric with strong water-absorbing.

Structural Diagram
